Reyee Cloud Managed PoE Switch RG-ES228GS-P 28xGigabit Ports Switch Sim Lim Square POE Switch Cheapest POE Switch Singapore NEW

Reyee RG-ES228GS-P Cloud Managed PoE Switch | 28-Port Gigabit CCTV Switch | Ruijie Cloud | Affordable PoE Switch Singapore

The Reyee RG-ES228GS-P is a 28-port Gigabit cloud-managed PoE switch designed for CCTV surveillance, offices, retail shops, warehouses, commercial buildings and SME network installations.

Its combination of 24 Gigabit PoE/PoE+ ports, 4 Gigabit SFP uplinks, high PoE power capacity, long-distance CCTV transmission features and Ruijie Cloud management makes it an attractive solution for projects requiring many IP cameras or other PoE devices.

For Singapore buyers searching for a cost-effective 24-port PoE switch at Sim Lim Square, the RG-ES228GS-P is worth considering against conventional unmanaged PoE switches because it adds remote monitoring and management capabilities.

Key Specifications

Ruijie’s technical documentation confirms that the RG-ES228GS-P belongs to its smart CCTV switch family and supports the extended-distance feature. Ruijie also documents a 370W overall PoE power threshold for this switch family. (Ruijie Community)

24 Gigabit PoE Ports

The RG-ES228GS-P provides 24 PoE-capable Gigabit Ethernet ports.

This makes it particularly useful for:

IP CCTV Cameras

Wireless Access Points

VoIP Phones

Door Access Devices

IP Intercoms

Other PoE Network Equipment

A typical CCTV installation can be:

24 × IP Cameras

↓

RG-ES228GS-P

↓

NVR / Server / Router

Instead of installing separate power adapters beside every camera, compatible devices can receive power and network data through the Ethernet cable.

4 × Gigabit SFP Uplink Ports

The additional 4 SFP interfaces provide greater flexibility for network uplinks.

This is particularly useful when connecting:

Building A → Fibre → Building B

or:

CCTV PoE Switch → Fibre Backbone → Main Server Room

Fibre is useful for longer-distance building links and electrically noisy environments where conventional copper Ethernet may not be appropriate.

Up to 370W PoE Capacity

A major consideration when selecting a CCTV PoE switch is not simply the number of ports.

You must also calculate the total PoE load.

For example:

24 cameras × 8W average = 192W

However, PTZ cameras, IR cameras, heaters and high-power wireless devices can consume considerably more.

Ruijie’s documentation identifies a 370W total device PoE threshold for the relevant implementation. (Ruijie Community)

This provides substantially more flexibility for multi-camera installations than low-budget PoE switches with limited total power.

Ruijie Cloud Management

One of the key advantages of Reyee networking products is Ruijie Cloud.

Instead of travelling to site simply to check a network port, administrators can use supported cloud-management functions to inspect and manage the switch remotely.

Ruijie’s cloud documentation shows switch management capabilities including port status, speed, traffic, VLAN ID and PoE status. Depending on model and firmware, administrators can also manage port settings and PoE functions. (Ruijie Networks Japan Cloud)

Ruijie Cloud

Remote PoE Management for CCTV

Remote PoE control can be extremely useful for CCTV maintenance.

Consider:

Camera Offline

Instead of immediately sending a technician to site:

Login Cloud → Check Switch → Check Port → Check PoE Status → Troubleshoot

Where supported, a PoE port can be administratively controlled through the management interface.

This can reduce unnecessary onsite troubleshooting for certain network or power-related camera problems. Ruijie’s Cloud switch interface includes dedicated PoE status and configuration functions, though the exact options vary by switch model and firmware. (Ruijie Networks Japan Cloud)

Up to 250m Long-Distance CCTV Transmission Mode

Standard Ethernet copper runs are normally designed around a 100m channel limitation.

However, Ruijie specifically identifies the RG-ES228GS-P among its ES-series switches supporting transmission distances of up to 250 metres using the applicable long-distance mode. (Ruijie Community)

This can be useful for CCTV installations such as:

• Factories
• Warehouses
• Car Parks
• Condominiums
• Guardhouses
• Perimeter Cameras
• Remote Gates
• Large Commercial Buildings

Performance and link speed can be affected in extended-distance modes, so proper cable quality and project design remain important.

Designed for CCTV Networks

The RG-ES228GS-P is especially attractive for surveillance because a CCTV network commonly requires:

Many PoE Ports + High Power Budget + Long Cable Runs + Remote Troubleshooting + Fibre Uplinks

For example:

24 × IP Cameras

↓

RG-ES228GS-P PoE Switch

↓

Fibre / Gigabit Uplink

↓

NVR

↓

Router / Internet

↓

Remote Monitoring

This provides a clean architecture for medium-sized IP CCTV installations.

VLAN for CCTV Network Separation

A managed switch allows a network designer to logically separate devices using VLANs.

For example:

VLAN 10 – Office Computers

VLAN 20 – CCTV Cameras

VLAN 30 – Door Access

VLAN 40 – Wi-Fi

This can improve network organisation and security when the router/firewall and overall network are configured correctly.

Remote Firmware Management

Ruijie’s cloud platform also supports online firmware management for supported devices, including checking versions and performing upgrades. (Ruijie Networks Japan Cloud)

For installers managing multiple customer sites, centralised management can significantly simplify maintenance compared with independently managing every switch onsite.

Important: RG-ES228GS-P Is Not an Enterprise SNMP Switch

One specification is important to understand before purchasing.

Ruijie’s published support information lists the RG-ES228GS-P as not supporting SNMP v1, v2c or v3.

Therefore, if your project specification explicitly requires:

SNMP + Enterprise NMS + Advanced Layer 2/Layer 3 Features

you should consider a higher-level Ruijie managed-switch series instead.

For many CCTV, SME and straightforward cloud-managed PoE applications, however, the RG-ES228GS-P offers a useful balance of features and cost.

Sim Lim Square PoE Switch Singapore

The RG-ES228GS-P is suitable for customers searching for:

• 24-Port PoE Switch Singapore
• 28-Port Gigabit Switch
• CCTV PoE Switch
• Cloud Managed PoE Switch
• Affordable PoE Switch Singapore
• Sim Lim Square PoE Switch
• Ruijie Switch Singapore
• Reyee Switch Singapore
• IP Camera PoE Switch
• Long Distance PoE Switch
• Fibre Uplink CCTV Switch

For SEO, I recommend using “Affordable PoE Switch Singapore” or “Cost-Effective PoE Switch Singapore” rather than claiming “Cheapest PoE Switch Singapore” unless you are continuously comparing all current market prices.

SGCCTV Reyee / Ruijie Network Solutions Singapore

SGCCTV – Choicecycle CCTV Pte Ltd provides Reyee and Ruijie network solutions for CCTV, business networks and commercial installations, including PoE switches, managed switches, fibre networking, CAT6 cabling, VLAN configuration, CCTV networking, switch troubleshooting and system upgrading.

Website: www.sgcctv.com.sg
Email: enquiry@choicecycle.com.sg
WhatsApp: +65 9853 4404

10 Frequently Asked Questions

1. What is the Reyee RG-ES228GS-P?
It is a high-port-count Gigabit PoE smart/cloud-managed switch designed for CCTV and SME network applications.

2. How many PoE ports does RG-ES228GS-P have?
It provides 24 Gigabit PoE/PoE+ copper ports, making it suitable for large groups of IP cameras and other PoE devices.

3. Why is it described as a 28-port switch?
It combines 24 Gigabit PoE RJ45 ports with 4 Gigabit SFP interfaces, giving 28 physical network interfaces.

4. What is the maximum PoE budget?
Ruijie’s documentation references an overall 370W PoE power threshold for this switch implementation. (Ruijie Community)

5. Can it power CCTV cameras?
Yes. It is specifically suitable for PoE IP-camera networks, subject to each camera’s PoE requirements and the switch’s total power budget.

6. Can RG-ES228GS-P be remotely managed?
Yes. Ruijie provides cloud-based switch management capabilities through its cloud platform. (Ruijie Networks)

7. Can it support long-distance CCTV cabling?
Ruijie identifies the RG-ES228GS-P among its ES switches capable of supporting transmission distances up to 250m using the applicable extended-distance feature. (Ruijie Community)

8. Does it support fibre connections?
Yes. Its SFP interfaces can be used with compatible modules and fibre infrastructure.

9. Does RG-ES228GS-P support SNMP?
Ruijie’s published support information lists SNMP v1, v2c and v3 as unsupported for the RG-ES228GS-P.

10. Is it suitable for a 24-camera CCTV system?
Yes, it can be a strong option for a 24-camera PoE system, provided the total camera PoE load, network bandwidth and uplink requirements are calculated correctly.

15 Facebook Hashtags

#Reyee #Ruijie #RGES228GSP #ReyeeSwitch #RuijieSwitch #PoESwitch #24PortPoE #28PortSwitch #GigabitSwitch #CloudManagedSwitch #CCTVSwitch #CCTVSingapore #SimLimSquare #SGCCTV #Choicecycle

Overview

The RG-ES228GS-P is a 28-port gigabit smart cloud-managed PoE switch designed for enterprise, hospitality, factory, education, retail, and surveillance applications. With its 24 PoE+ ports, 2 RJ45 ports, and 2 SFP ports, this switch is an ideal solution for businesses requiring high-performance networking with intelligent power management. It ensures seamless connectivity, robust security, and simplified management through Ruijie Cloud.

Key Features

• High Power PoE+: 24 PoE+ ports with 370W total power budget, supporting IEEE 802.3at/af.
• Smart Cloud Management: Ruijie Cloud offers zero-touch provisioning, remote monitoring, and configuration via the mobile app.
• Automatic Loop Prevention: Ensures continuous network stability by automatically detecting and preventing network loops.
• CCTV Optimized: Supports IP camera/NVR recognition, intelligent PoE adaptation, and 250m transmission distance in extend mode.
• Flexible VLAN Management: Supports mobile VLAN configuration and port isolation for enhanced security.
• High-Speed Data Handling: Switching capacity of 56 Gbps and forwarding rate of 41.664 Mpps ensure high-performance data transfer.
• Robust Build Quality: Built-in fan for effective cooling with automatic operation below 25°C.

Technical Specifications

• Ports: 26 x 10/100/1000Base-T (24 PoE+), 2 x 1000Base-X SFP
• PoE Power Budget: 370W
• Switching Capacity: 56 Gbps
• Forwarding Rate: 41.664 Mpps
• MAC Address Table: 8,000
• Maximum VLANs: 16
• Port Surge Protection: 4 kV
• Fan: Built-in, stops running below 25°C
• Dimensions: 440 mm x 214.9 mm x 44 mm
• Weight: 4.0 kg (with package)
• MTBF: >200,000 hours
• Operating Temperature: 0°C to 40°C
• Operating Humidity: 10% to 90% RH
• Certification: CE, FCC
• Warranty: 3 Years

Why Choose RG-ES228GS-P?

• Optimized for CCTV & Surveillance: Intelligent PoE allocation and real-time monitoring ensure seamless IP camera performance.
• Reliable & Secure: Advanced network security features like port isolation, flow control, and broadcast storm suppression.
• Smart Cloud Management: Monitor switch statistics, configure VLANs, and troubleshoot issues from anywhere with the Ruijie Cloud App.
• Easy Deployment: SON (Self-Organizing Network) and zero-touch provisioning simplify installation.
• Energy Efficient: Intelligent power management and fan control lower energy consumption.

Contact Us

Store Location:
SGCCTV Choicecycle, Sim Lim Square CCTV Specialist #02-81

Operating Hours:
11 AM – 8 PM

WhatsApp:
+65 98534404 (for stock inquiries before visiting)

Email:
enquiry@choicecycle.com.sg

Website:
https://sgcctv.com.sg

Conclusion

The RG-ES228GS-P is a cutting-edge, cloud-managed PoE switch designed to meet the networking demands of businesses across various industries. With its powerful performance, intelligent security, and seamless cloud integration, it ensures reliability and efficiency in every setup. Whether you’re enhancing surveillance networks, optimizing enterprise IT infrastructure, or expanding retail connectivity, this switch delivers superior functionality. Contact us today to learn more or place an order!
