CHOICECYCLE CCTV offer the best Solar-Powered CCTV KIT/DH-PFM364L-D1/DH-IPC-HFW4230MP-4G-AS-I2/DH-PFB121W Sim Card Security Camera Solar CCTV Surveillance 4G LTE Solar CCTV IP Camera.



Features:

1. Solar-Powered: Equipped with a solar panel to harness solar energy, allowing for off-grid operation.
2. Sim Card Security: Supports a SIM card for 4G LTE connectivity, enabling remote access and surveillance without relying on traditional wired networks.
3. 4G LTE Connectivity: Provides high-speed mobile internet access, ensuring a stable connection for remote monitoring and data transmission.
4. HD IP Camera (DH-IPC-HFW4230MP-4G-AS-I2): High-definition camera with advanced features, offering clear and detailed video footage.
5. Solar Charge Controller (DH-PFM364L-D1): Manages the solar power system, optimizing the charging process and preventing overcharging of the batteries.
6. Wireless Connectivity: With 4G LTE, the system allows for remote monitoring without the need for wired internet connections.
7. Weatherproof (DH-PFB121W): Designed to withstand various weather conditions, making it suitable for outdoor use.

Functions:

1. Remote Access: Users can access live or recorded footage remotely through smartphones, tablets, or computers.
2. Motion Detection: The camera may feature motion detection capabilities, triggering alerts and recordings when movement is detected.
3. Night Vision: Infrared or low-light technology enables the camera to capture clear images in low-light or nighttime conditions.
4. Two-Way Audio: Allows for communication through the camera, enabling users to listen and speak to individuals in the monitored area.
5. Pan-Tilt-Zoom (PTZ): If applicable, PTZ functionality enables users to remotely control the camera’s movement for a wider field of view.

Benefits/Advantages:

1. Off-Grid Operation: Solar-powered and rechargeable batteries enable operation in areas without traditional power sources.
2. Wireless Connectivity: 4G LTE connectivity provides flexibility in camera placement without the need for wired internet infrastructure.
3. Remote Monitoring: Users can monitor their property or premises from anywhere with a stable 4G LTE internet connection.
4. Quick Installation: Typically, wireless and solar-powered setups require less installation effort and are suitable for various environments.
5. Environmentally Friendly: Solar-powered solutions contribute to environmental sustainability by utilizing renewable energy.

Before purchasing, it’s essential to verify the specifications, compatibility with your specific requirements, and the reliability of the brand or manufacturer. Reading user reviews can also provide insights into the real-world performance of the product.



Integrated Solar Monitoring System (Optional Lithium Battery) Solar Power System

Setup Manual CCSOLAR4G

1. Collection from SGCCTV Choicecycle Sim Lim Square CCTV SPECIALIST #02-81 11am~8pm. Whatsapp 90254466 for stock level.
2. Payment by PayNow 90254466 & Paylah QR code will receive Free Gift Warning Stickers worth $20.00 (1pc per client order)
3. Please add $18.00 for delivery – 3~5 days, no further discount as Price guarantee lowest.
4. Can issue e-Invoice for your accounting. (upon request)

Dahua WizSense Human Vehicle Detection Perimeter Protection  ||  Dahua Video Intercom FACT ASI3214A-W ASI3213A-W ASI3223A ASA3223A-W  ||

DAHUA DAHUA Smart Dual Illuminators Network PT Camera || 2MP HD-CVI Bullet Camera || 2MP HD-CVI Dome Camera ||

2MP Dome IPC HDBW2230E  ||  2MP Bullet IPC-HFW2431S-S-S2 || 5MP FISHEYE IPC-EW5541-AS  || 8MP 4K IPC-HDBW2831E-S-S2 ||
8MP IPC-HFW2831S-S-S2  || 4MP PTZ IPC-HDBW5431RPZE || 25x PTZ DH-SD49225T-HN  || 25x DH-SD49225XA-HNR  ||

More Common choice to meet your needs: C2PP || Fisheye 360 degree CC380PF ||  C1C  || C1HC || C3A Battery Camera || C6CN  ||  C6TC  || HIK Q1  || USB2052MP  || Dahua 2C  ||  5G 2.4G Pan Tilt Camera CC524PT  ||

More Choice : Battery-Powered Camera BC1-B1  || IP CAMERA Outdoor C3W  ||  Hikvision 5MP Fisheye DS-2CD2955FWD-I  ||  Dual-Band IP CAMERA 5G C6P  ||  IP Camera Dual-band 2.4-5G   ||
12MP Fisheye-Network Camera CC81IPC59AE  ||

Solar-Powered CCTV KIT/DH-PFM364L-D1/DH-IPC-HFW4230MP-4G-AS-I2/DH-PFB121W Sim Card Security Camera Solar CCTV Surveillance 4G LTE Solar CCTV IP Camera



How to Choose and Install Solar-Powered Battery CCTV Security Camera

Choosing a solar-powered battery CCTV security camera can seem daunting, but by following a few simple steps, you can make an informed decision.

1. Determine your surveillance needs: Consider the areas you want to monitor, the level of security you need, and the number of cameras required.
2. Research available options: Look for cameras that are specifically designed for outdoor use and have features like night vision, motion detection, and remote access.
3. Check the power requirements: Make sure the camera is designed to run on solar power and check the battery capacity.
   Look for cameras with large battery capacities, so they can run for an extended period without recharging.
4. Choose the right location: The camera should be installed in a location that receives plenty of sunlight throughout the day. It is important to avoid areas that are shaded or receive limited sunlight.
5. Install the camera: Once you have selected the camera, you can begin installation.
   Follow the manufacturer’s instructions carefully, and make sure to place the camera at the correct angle for optimal performance.
6. Test the camera: After installation, test the camera to make sure it is working correctly.
   Check the video quality, motion detection, and remote access to ensure everything is functioning as expected.
7. Maintenance: Check the camera periodically to ensure it is clean and free from obstructions that may affect its performance. Make sure the battery is charged and functioning correctly.

By following these steps, you can choose and install a solar-powered battery CCTV security camera that will provide reliable and efficient surveillance for your property.

Integrated Solar Power System (without Lithium Battery)

Model

DH-PFM364L-D1

Solar Panel

Type

Monocrystalline silicon

Max. Power

60W

Solar Cell Efficiency

21%

Max. Mechanical Load

5400Pa

Protection

Over-discharge Protection Voltage

11.1V DC

Low Temperature Charging

≤–10°C (14°F)

Low Temperature Discharging

≤–20°C (–4°F)

Grade

IP66

Others

Over temperature, overvoltage of the battery, overload, and short circuit

Port

Power Output

Φ5.5 mm × Φ2.1 mm × 12 mm(Φ0.22″ × Φ0.08″ × 0.47″)

RS–485

1

General

Main Body Material

Die casting aluminum

Installation

Pole mount, installed on 76 mm to 96 mm (Φ3.0″–Φ3.78″) poles

Adjustable Angle

Horizontal: 0°–360° Vertical: -75°–80°

Product Dimensions

1149.5 mm × 367.6 mm × 430.2 mm (45.26″ × 14.47″ × 16.94″)

Packaging Dimensions

1353 mm × 548 mm × 364 mm (53.27″ × 21.57″ × 14.33″)

Packaging Method

1 pc in each carton

Net Weight

16 kg (35.27 lb)

Gross Weight

22.5 kg (49.60 lb)

Environment

Operating Altitude

<3000 m (9842.5 ft)

Applicable Area

Areas with daily solar radiation>4.5 h

Operating Temperature

–20°C to 60°C (–4°F to 140°F)

Operating Humidity

<95% (RH)

Storage Temperature

0°C to 40°C (32°F to 104°F)

Storage Humidity

<95% (RH)

Certifications

Certifications

CE: EN61000-6-2, EN61000-6-4 FCC: FCC Part 15 Subpart B

2MP 4G IR Bullet Network Camera

Model

DH-IPC-HFW4230M-4G-AS-I2

Camera

Image Sensor

1/2.9″ 2Megapixel progressive scan CMOS

Effective Pixels

1920(H) × 1080(V)

RAM/ROM

256 MB/32 MB

Scanning System

Progressive

Minimum Illumination

0.04 Lux/F2.0 ( Color,1/3 s,30IRE) 0.22 Lux/F2.0 ( Color,1/30 s,30IRE) 0 Lux/F2.0 (IR on)

S/N Ratio

More than 56 dB

IR Distance

Distance up tp 40 m (131.2 ft)

IR On/Off Control

Auto/ Manual

IR LEDs

2

Lens

Lens Type

Fixed

Mount Type

M12

Focal Length

3.6 mm (6 mm optional)

Max. Aperture

F2.0

Angle of View

H: 82.5° (51.5°), V: 44° (29.5°)

Optical Zoom

N/A

Focus Control

Fixed

Close Focus Distance

0.9 m (2 m) 29.5 ft (6.56 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6 mm

53 m (174 ft)

21 m (69 ft)

10 m (33 ft)

5 m (17 ft)

6 mm

80 m (262 ft)

32 m (105 ft)

16 m (52 ft)

8 m (26 ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

N/A

Intelligence

Event Trigger

Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly

IVS

Tripwire, Intrusion

Video

Compression

H.265/H.264H/MJPEG (Sub Stream)

Smart Codec

Support H.265/H.264

Streaming Capability

2 Streams

Resolution

1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576)/720P (1280 × 720)/D1 (704 × 576)/VGA (640 × 480)/CIF (352 × 288)

Frame Rate

Main Stream: 1080P@25 fps

Sub Stream: D1@25 fps

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32–10240 Kbps; H.265: 12–6400 Kbps

Day/Night

Auto ICR

BLC Mode

BLC / HLC / DWDR

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto

Noise Reduction

3D DNR

Motion Detection

Off/On (4 Zone, Rectangle)

Region of Interest

Off/On (4 Zone)

Electronic Image Stabilization(EIS)

N/A

Smart IR

Yes

Defog

N/A

Digital Zoom

N/A

Flip

0°/90°/180°/270°

Mirror

Off/On

Privacy Masking

Off/On (4 Areas, Rectangle)

Audio

Compression

G.711a/G.711Mu/AAC/G.726

Network

Ethernet

RJ-45 (10/100Base-T)

Mobile Communication

4G

Operating band

Model 1: TDD-LTE: Band38/39/40/41 FDD-LTE: Band1/3/5/8 WCDMA: Band1/8 TD-SCDMA: Band34/39 EVDO/CDMA1X: BC0 GSM: Band3/8 Model 2: FDD-LTE: Band1/2/3/4/5/7/8/20 UMTS: Band1/2/5/8 GSM: 850/900/1800/1900

Protocol

HTTP; HTTPS; TCP; ARP; RTSP; RTP; RTCP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPV4/V6; QoS; UPnP; NTP; Bonjour; IEEE 802.1X; Multicast; ICMP; IGMP; TLS

Interoperability

ONVIF Profile S&G, API

Streaming Method

Unicast/Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS Local PC for instant recording Mirco SD card 256 GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Solar-Powered CCTV KIT/DH-PFM364L-D1/DH-IPC-HFW4230MP-4G-AS-I2/DH-PFB121W Sim Card Security Camera Solar CCTV Surveillance 4G LTE Solar CCTV IP Camera   Certifications

Certifications

CE-LVD: EN60950-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B

Smart Phone

IOS, Android

Interface

Audio Interface

1/1 channel In/Out

Alarm

2 channels In: 500mA 5VDC 2 channels Out: 300mA 12VDC

Electrical

Power Supply

DC12V±30%

Power Consumption

3.6W, 9.5W (IR on);6W (4G on, IR off)

Environmental

Operating Conditions

–30°C to +60°C (–22°F to +140°F)/Less than 95% RH

Storage Conditions

–30°C to +60°C (–22°F to +140°F)/Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

N/A

Construction

Casing

Metal + Plastic

Dimensions

194.4 mm × 96.6 mm × 89.5 mm (7.65″ × 3.8″ × 3.52″)

Net Weight

0.7 kg (1.54 lb)

Gross Weight

0.8 kg (1.76 lb)

Wall Mount Bracket

Model

DH-PFB121W

General

Material

Aluminum

Dimension (W×H×D)

58 mm × 88 mm × 190.5 mm (2.28″ × 3.46″ × 7.50″)

Weight

0.24 kg (0.53 lb)

Load Bearing

1 kg (2.2 lb)

Color

White

Operating Temperature

–40°C to +60°C (–40°F to +140°F)

Humidity

<90% RH

Applicable Model

Please check “Accessory Selector” on DAHUA website
