HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB PIR Motion Detector DS-PD2-P10PE

HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB PIR Motion Detector DS-PD2-P10PE INTRUDER ALARM SYSTEM HOME OFFICE ALARM SYSTEM INSTALLATION

CHOICECYCLE CCTV offer the Best HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB.
PIR Motion Detector DS-PD2-P10PE INTRUDER ALARM SYSTEM HOME OFFICE ALARM SYSTEM INSTALLATION

AX HYBRID PRO DS-PHA64-LP

Features and Functions

• Hybrid system: 8 on-board zones and 56 wired/wireless zones expandable; 4 on-board outputs (2 relay outputs and 2 I/O outputs) and 60 wired/wireless outputs expandable
• Dual-path communication of alarm events and other signals over LAN, PSTN, Wi-Fi, GPRS or 3G/4G utilizing a main and backup channel with configurable priority
• 4-ch onboard IP Camera video verification, supports video recording (5s pre-alarm + 2s post-alarm, or 2s pre-alarm + 5s post-alarm) for verification to the alarm receiving email or mobile client
• Supports arming/disarming via keypad, keyfob, mobile client, iVMS-4200, SMS and tag
• Pushes alarm notification via messages and Hik-Connect
• Supports ISAPI, Cloud P2P, ISUP, CSV-IP and DC-09 protocol
• Supports 1 Speed-X BUS



Wired LCD Keypad DS-PK1-LRT-HWB

Features and Functions

• LCD screen display
• Supports one-touch arm (Arming without password）
• Supports Fire/Panic/Medical alarm key
• Supports company name, phone number, time display
• Supports 2 on-board alarm inputs and 1 on-board alarm output
• Supports maximum 64 key-fobs

Wired internal 10m PIR detector DS-PD2-P10PE with Pet immunity functions

Features and Functions

• Detection range: 10 m x 10 m, 85 degrees
• PIR motion detection
• Pet immunity up to 24 kg
• Supports creep area protection
• Adjustable EOL reduces construction costs
• Supports tamper protection
• Digital temperature compensation
• Automatic sensitivity
• Independent floating threshold (IFT)



Features:

Wireless Connectivity: Indicates that it operates wirelessly, providing flexibility in placement.
Emergency Button: Designed for manual activation in emergency situations.
Functions:

Emergency Alert: Can trigger emergency alerts when pressed, signaling the need for immediate attention or assistance.
Benefits and Advantages:

Quick Response: Provides a quick and direct method for individuals to signal emergencies.
Wireless Design: Easy to deploy without the need for complex wiring.
Integration: Can be integrated into a broader security or alarm system for a coordinated response.
Intruder Alarm System:

Installation:

Home, Office, Factory: Suitable for installation in various environments, including homes, offices, and factories.
Professional Installation: For optimal performance, it’s advisable to have the alarm system installed by professionals.
Features and Functions:

AX-PRO Series: If part of the AX-PRO series, it may offer advanced features such as wireless connectivity, mobile app integration, and compatibility with various sensors.
Integration with Security Devices: The system may integrate with a variety of security devices, including door/window sensors, motion detectors, and cameras.
Alarm Monitoring: Capable of monitoring and alerting users or a central monitoring station in the event of unauthorized access or emergencies.
Benefits and Advantages:

Comprehensive Security: Provides a comprehensive security solution for intrusion detection.
Remote Monitoring: Allows for remote monitoring and management through mobile apps or web interfaces.
Scalability: Can be expanded with additional sensors and devices to meet specific security requirements.

HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB PIR Motion Detector DS-PD2-P10PE INTRUDER ALARM SYSTEM HOME OFFICE ALARM SYSTEM INSTALLATION

Hikvision AX PRO alarm system of the latest generation. AX Pro Setup Video  || Full Setup Manual for HIKvision Qualified Technician  ||

Home Security is important, which will rise your protection to a new level.  AX PRO supports Wi-Fi, TCP/IP, and GPRS/3G/4G communication methods.
It also supports Hik-ProConnect, Hik-Connect, Hik IP Receiver, Hik IP Receiver Pro and Hik-Central,
which is applicable to the scenarios of home, office, market, store, house, factory, warehouse, office, etc.
The kit has an easy-installation setup, Plug & Play, User Friendly, a lot of coverage and doesn’t require messy ugly cabling.

It can be directly connected to the app to ease the process of controlling the situation.
Everything in one app supports Hik-Connect. Central monitoring of an alarm system, video surveillance and door intercom from an interface.

1. Collection from SGCCTV   Choicecycle Sim Lim Square CCTV SPECIALIST #02-81 11am~8pm. Whatsapp 98534404 for stock level before visit.

2. Payment by PayNow 201207820G or QR code will receive Free Gift Warning Stickers worth $20.00 (1pc per client order)
3. Please add $18.00 for delivery – 3~5 days.
4. Can issue e-Invoice for your accounting. (upon request)

1. Collection from SGCCTV   Choicecycle Sim Lim Square CCTV SPECIALIST #02-81 11am~8pm. Whatsapp 98534404 for stock level before visit.

2. Payment by PayNow 201207820G

HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB PIR Motion Detector DS-PD2-P10PE INTRUDER ALARM SYSTEM HOME OFFICE ALARM SYSTEM INSTALLATION

• Hardware features
• Tag reader built in1 Built-in Tag Reader
• Serial port1 TTL Serial Port
• Tamper-Proof1 Back-cover Tamper-switch（Will be damaged when tamper triggered）
• Buzzer1 On-board Buzzer
• Function key8 Function keys：Query，Away Aram，Stay Arm，Disarm，Alarm Output，Project，Left，Right
• RS-4851 Speed-X bus
• Alarm input2 On-board Alarm inputs
• Alarm output1 On-board Alarm output
• Electrical characteristics
• Power supply10.2 to 14.4 VDC
• Typical voltage12 VDC
• Power consumption

  Maximum current: 150mA@12VDC

  Quiescent current: 72mA@12VDC

• Wireless transmission
• RF frequency433MHz

• Display
• Numeric key0 to 9，*，#
• Display screenLCD Screen
• Indicator

  4 indicators and 1 backlight：

  1. Power：Green

  2. Faults：Fault-Orange / Alert-Flashing orange / Find me mode-flashing green

  3. Armed：Blue

  4. Alarm：Red

  5. Keypad button backlight：White

• General
• Dimension(WxHxD)150mmx115mmx28mm
• ColorWhite
• Operation temperature– 10 °C to + 55 °C (14 °F to 131 °F)
• Operation humidity10%～90%

• Device management
• Keyfob64

HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB PIR Motion Detector DS-PD2-P10PE INTRUDER ALARM SYSTEM HOME OFFICE ALARM SYSTEM INSTALLATION

• Software features
• Zones64 (8 On-board zones, max 8 wired PIRCAM)
• Area32
• User

  Installer: 1

  Administrator: 1

  Operator: 62

• SMS notification Support (with GPRS/3G/4G module)
• Onboard video clips4
• ARC protocol

  ISAPI: Supports iVMS-4200 client software and web client

  Cloud P2P: Supports cloud P2P privacy protocol

  DC-09: ARC accessible ADM-CID/SIA-DCS ）

  CSV-IP: Supports CSV-IP

  ISUP: Supports ISUP 5.0

• Programming tools Web/iVMS-4200/Hik-Pro Connect/Keypad
• Firmware upgrade Web/iVMS-4200/Hik-Pro Connect/Hik-Pro Connect
• End of Line Resistance Support 1K, 2.2K, 4.7K, 5.6K, 6.8K, 8.2K

• Hardware features
• Alarm input64 (Including 8 on-board zones)
• Alarm output64 (Including 2 on-board relay outputs and 2 on-board I/O outputs)
• Power Output

  1. Bell: maximum 12V 1.2A

  2. AUX: maximum 12V 1.5A

  3. Bell and AUX maximum 12V 2.1A

• 3/4G on board Optional
• GPRS on board Optional
• Wi-Fi802.11b/g/n (2.4GHz)
• Bus1 Speed-X bus
• Sounder output1 Wired on-board sounder output
• Tamper-Proof

  1 switch to detect removal from mounting

  1 switch to detect front cover open

• Network interface1 RJ45 10M/100M Ethernet interface

• Electrical characteristics
• Power interface100 to 240 VAC (on-board power transformer)
• Power Consumption

  1. 220V power supply

  ① With an alarm: 2A, 32W

  ② Without an alarm: 250mA, 4W

  2. 13.5V battery supply

  ① With an alarm: 1.7A, 25W

  ② Without an alarm: 200mA, 2.7W

• Battery type Lead acid battery (12V 7Ah, battery is not included by default)
• Battery life span Up to 36hrs

• Display
• Indicator

  4 On-board LEDs:

  ① 1 AC power LED indicator (Green)

  ② 1 System status LED indicator (Green/Red)

  ③ 1 PSTN status LED indicator (Green/Red)

  ④ 1 Mobile communication status LED indicator (Green/Red)

• General
• Operation temperature-10°C to 40°C
• Operation humidity10% to 90%
• Shell material Plastic
• Color White
• Dimension (WxHxD) 261 mm × 199 mm × 86.4 mm
• Weight997 g

• Device management
• Tag64
• Keyfob64
• Keypad8
• Wireless sounder16



Features and functions for home and office intruder alarm system,



1. Wireless Connectivity: Many modern alarm systems use wireless technology for easy installation and flexibility in placement of sensors and devices.
2. Motion Sensors: Motion sensors are used to detect movement within a defined area. They are often placed in key locations to trigger an alarm if an intruder enters.
3. Door and Window Sensors: These sensors detect when a door or window is opened or closed. They are essential for protecting entry points.
4. Control Panel: The control panel is the central hub of the alarm system. It allows you to arm and disarm the system and communicates with the various sensors.
5. Siren or Alarm Sound: An audible alarm is triggered when the system detects an intrusion. This sound serves as a deterrent and alerts people in the vicinity.
6. Remote Monitoring: Many alarm systems offer remote monitoring capabilities through smartphone apps or web interfaces.
   This allows you to receive alerts and monitor your system from anywhere.
7. Real-time Notifications: You can receive notifications via email, SMS, or push notifications when the alarm is triggered.
8. Key Fobs or Remote Controls: Key fobs or remote controls allow you to arm and disarm the system without needing to enter a code on the control panel.
9. Backup Power: Alarm systems typically have a backup power source, such as a battery, to ensure they remain operational during power outages.
10. Security Cameras (optional): Some alarm systems, especially those designed for larger properties or commercial use, may include security cameras for video surveillance.
11. Zones and Customization: Systems often allow you to define different zones within your property and customize how each zone is monitored.
12. Integration with Smart Home Devices: Some alarm systems can integrate with other smart home devices, such as smart locks, lights, and thermostats, allowing you to create automation routines.
13. Professional Monitoring (optional): Some alarm systems offer professional monitoring services, where a security company monitors your system 24/7 and dispatches authorities in case of an alarm.



HIKVISION ALARM AX-HYBRID-PRO DS-PHA64-LP LCD Keypad DS-PK1-LRT-HWB PIR Motion Detector DS-PD2-P10PE INTRUDER ALARM SYSTEM HOME OFFICE ALARM SYSTEM INSTALLATION

• Detection performance
• Detection Range10m
• Detection Angle85°
• Velocity range0.3m/s to 3.0m/s
• Pet ImmunityUp to 24kg

• Electrical characteristics
• Power supply9-16V DC
• Typical Voltage12VDC

• General
• Operation temperature-10℃ ~ +40℃
• Dimension(WxHxD)69mm*117mm*50mm
• Weight125g
• Application scenarioIndoor
• Installation height1.8 ~ 2.4m
• Installation methodWall mounted or Ceiling mounted
• Bracket Including 1 x Ceiling mounting bracket, 1 x Wall mounting bracket
